S318
Active Point Source
Entwickelt in Terrassa
Perspective·1 / 3
Funktionen
Highlight
Amate Audio’s latest generation DSP system management is integrated with 3rd generation Class D amplification. Colour touchscreen operation and monitoring of DSP system includes access to powerful presets – engineered by Amate Audio’s R&D team – that instantly configure your Nítid loudspeaker for the majority of common application environments within seconds, prior to rigging or installation.
Die Daten
SPL
133 dB
POWER
3200 W
COVERAGE
60° (H) × 50° (V)
WEIGHT
63 kg
Akustische Leistung
| Frequency response (-10 dB) | 35 Hz to 19 kHz |
| Maximum SPL (1 m) | 133 dB |
| Coverage (-6 dB) | 60° (H) × 50° (V) |
Verstärkung
| Configuration | Active three-way (main PA / sidefill / drumfill) |
| Amplifier power | 2400 W (LF) + 800 W (HF), Class D bi-amp |
DSP und Steuerung
| Built-in DSP | 64-bit with touchscreen |
| Filtering | FIR filters |
| Presets | Factory presets |
Maße und Gewicht
| Dimensions (H × W × D) | 1230 × 520 × 540 mm |
| Weight | 63 kg |
Spezifikationen aus der Amate Audio Produktübersicht, März 2026. Änderungen ohne Vorankündigung vorbehalten.
