S12W
Subwoofer
Entwickelt in Terrassa
Perspective·1 / 7
Funktionen
Highlight
Amate Audio’s latest generation DSP system management is integrated with 3rd generation Class D amplification. Colour touchscreen operation and monitoring of DSP system includes access to powerful presets – engineered by Amate Audio’s R&D team – that instantly configure your Nítid loudspeaker for the majority of common application environments within seconds, prior to rigging or installation.
Die Daten
SPL
126 dB
FREQUENCY
38 Hz to 130 Hz
POWER
1000 W
WEIGHT
26.7 kg
Akustische Leistung
| Frequency response (-10 dB) | 38 Hz to 130 Hz |
| Maximum SPL (1 m) | 126 dB |
| Coverage (-6 dB) | Omnidirectional |
Verstärkung
| Configuration | 12" active subwoofer |
| Amplifier power | 1000 W, Class D |
DSP und Steuerung
| Built-in DSP | 64-bit with touchscreen |
| Filtering | FIR filters |
| Presets | Factory presets |
Maße und Gewicht
| Dimensions (H × W × D) | 384 × 520 × 582 mm |
| Weight | 26.7 kg |
Spezifikationen aus der Amate Audio Produktübersicht, März 2026. Änderungen ohne Vorankündigung vorbehalten.
