S15W
Subwoofer
Entwickelt in Terrassa
Perspective·1 / 6
Funktionen
Highlight
Amate Audio’s latest generation DSP system management is integrated with 3rd generation Class D amplification. Colour touchscreen operation and monitoring of DSP system includes access to powerful presets – engineered by Amate Audio’s R&D team – that instantly configure your Nítid loudspeaker for the majority of common application environments within seconds, prior to rigging or installation.
Die Daten
SPL
129 dB
FREQUENCY
35 Hz to 140 Hz
POWER
2000 W
WEIGHT
38.5 kg
Akustische Leistung
| Frequency response (-10 dB) | 35 Hz to 140 Hz |
| Maximum SPL (1 m) | 129 dB |
| Coverage (-6 dB) | Omnidirectional |
Verstärkung
| Configuration | 15" active subwoofer |
| Amplifier power | 2000 W, Class D |
DSP und Steuerung
| Built-in DSP | 64-bit with touchscreen |
| Filtering | FIR filters |
| Presets | Factory presets |
Maße und Gewicht
| Dimensions (H × W × D) | 463 × 630 × 680 mm |
| Weight | 38.5 kg |
Spezifikationen aus der Amate Audio Produktübersicht, März 2026. Änderungen ohne Vorankündigung vorbehalten.
