Productos/Electronics/LMS608
LMS608
Signal Processor
Diseñado en Terrassa
Perspective·1 / 3
LMS608
Características
Lo que lo distingue.
- Sound systems with passive speakers in applications where, due to room acoustics or type of music, corrections of the frequency response are needed (equalization)
- Sound systems with passive speakers for touring
- Fixed installations with different audio zones
- Hi-Impedance installations with either speaker intelligibility or SPL requirements
Los datos
Especificaciones
I/O
4+2 in / 8 out
SAMPLE RATE
96 kHz
DSP DEPTH
64-bit
ETHERNET
Yes
Rendimiento acústico
| Frequency response | 20 Hz to 20 kHz (±0.5 dB) |
| Input dynamic range | > 116 dB(A) |
Entradas / Salidas
| Analog inputs | 4 × XLR |
| Digital inputs | 2 × AES/EBU (1 × XLR) |
| Outputs | 8 × XLR |
| A/D converters | 24-bit, 96 kHz |
DSP y control
| Architecture | 64-bit |
| Per channel processing | 10 parametric EQ, 2 s delay, limiter, crossover, polarity |
| Configuration | Front-panel keypad and LCD, or PC and Mac |
| Networking | Ethernet control |
Físico
| Form factor | 1 U / 19" rack |
| Dimensions (H × W × D) | 44 × 483 × 165 mm |
| Weight | 2.5 kg |
Especificaciones de la Visión general de producto Amate Audio, marzo de 2026. Sujetas a cambios sin previo aviso.
Descargas
Especificaciones y recursos
Los archivos están alojados por Amate Audio. Los enlaces abren en amateaudio.com.
